描述
|
Type
|
Module
|
Powerwall
|
||
|
Model
|
LFP48V50AH
|
LFP48V100AH
|
LFP48V150AH
|
LFP48V200AH
|
|
Battery Capacity [Ah]
|
50Ah
|
100Ah
|
150Ah
|
200Ah
|
|
Nominal Battery Energy [kwh]
|
2.4
|
4.8
|
7.2
|
9.6
|
|
Max Discharge Current [A]
|
50
|
100
|
150
|
200
|
|
Net Weight
|
35
|
68
|
95
|
108
|
|
Dimension [H*W*D, mm]
|
442*480*88
|
680*495*185
|
680*495*185
|
680*495*185
|
|
Operating Temperature Range
|
-20 ~ 50 [℃ ]
|
|||
|
Life Cycles
|
>6000
|
|||
|
Nominal Voltage [V]
|
48Vdc
|
|||
|
Communication
|
CAN/RS485/DRY CONTACT
|
|||
|
Certificate & Safety Standard
|
TUV / CE / EN62619 / IEC62040 / UN38.3
|
|||
|
Warranty
|
10 Years
|
|||
|
Alarms
|
Battery Operation/Out of Battery/System fault
|
|||
|
Pros
|
Applied in off-grid and hybrid system, Compact Design, Modular Expansion
|
|||
|
Monitoring & Protection
|
With BMS protection in each Module, and breaker embedded in the system
|
|||
